Compact Laboratory Power Supply 0–30V / 0–10A — USB programmable
€79.00
In stock
SKU
TKP-ALM-LA-002
Lab power supply 0–30 V / 0–10 A, 300 W, TFT display, USB SCPI, M1–M5 memories
High-performance switching laboratory power supply 0–30 V / 0–10 A (300 W max). 2.4" color TFT display with 10 mV / 10 mA resolution. USB interface for PC software control (SCPI protocol). M1–M5 memories for quick configuration recall. Voltage regulation ≤ 0.05% + 10 mV, current regulation ≤ 0.1% + 20 mA. OVP (programmable overvoltage), OCP (overcurrent), OTP (overheat) protection. Variable speed ventilation. Universal 110–240 V AC input. Compact: 215 × 115 × 160 mm.
| Output Voltage | 0–60V Adjustable |
|---|---|
| Output Current | 0–10A Adjustable |
| Efficiency Rating | >90% |
| Regulated | Yes |
| Input Voltage | 100–240V AC |
| Output Connector | Screw Terminal |
| Brand | VoltCore |
| Mounting Type | DIN Rail |
| Voltage Compatibility | Multi-voltage |
| RoHS Compliant | Yes |
| Availability | Last Units |
| Packaging | Single |
