TMP36 Digital Temperature Sensor — Analog Output
€1.50
In stock
SKU
TKP-SEN-TE-007
TMP36 analog, −40/+125 °C, 10 mV/°C, TO-92, 2.7–5.5 V
TMP36 analog temperature sensor in TO-92 package. Linear voltage output with 500 mV offset: 10 mV/°C, i.e. 750 mV at 25 °C. Measurement range −40 °C to +125 °C. Accuracy ±1 °C from 0 to 70 °C, ±2 °C over extended range. 2.7 to 5.5 V power supply, typical consumption 50 µA. Unlike the LM35, the TMP36 allows reading negative temperatures without an inverting circuit. Natively 3.3 V compatible for ESP32 and Raspberry Pi.
| Sensor Type | Temperature |
|---|---|
| Measurement Range | -40°C à +125°C |
| Output Type | Analog |
| Accuracy | ±1°C |
| Digital Interface | No |
| Sensor Supply | 3.3V–5V |
| Brand | NanoSilicon |
| Mounting Type | Breadboard |
| Voltage Compatibility | 3.3V |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
