Resistive Soil Moisture Sensor — Probe Stake
€2.50
In stock
SKU
TKP-SEN-HU-001
Resistive soil moisture probe, analog+digital, LM393, 3.3–5 V
Resistive soil moisture sensor with two nickel-plated electrode probe, dimensions 60 × 30 mm. LM393 comparator module with analog output (0–4.2 V proportional to humidity) and digital output (threshold adjustable by potentiometer). 3.3 to 5 V power supply, current < 20 mA. 20 cm connection cable between probe and module. Threshold LED indicator. Applications: automatic irrigation, connected agriculture, smart gardening projects.
| Sensor Type | Temperature + Humidity |
|---|---|
| Measurement Range | 0 à 100% HR |
| Output Type | I²C |
| Accuracy | ±2% |
| Digital Interface | Yes |
| Sensor Supply | 3.3V–5V |
| Brand | NanoSilicon |
| Mounting Type | Breadboard |
| Voltage Compatibility | 5V |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
