MLX90614 Non-Contact Infrared Temperature Sensor — I²C
Special Price
€10.90
Regular Price
€12.90
In stock
SKU
TKP-SEN-TE-005
MLX90614 IR non-contact, −70/+380 °C, I²C, ±0.5 °C accuracy
MLX90614ESF-BAA non-contact infrared temperature sensor on breakout module. Measures object temperature −70 °C to +380 °C and ambient temperature −40 °C to +125 °C. Accuracy ±0.5 °C around body temperature. Resolution 0.02 °C, 90° field of view. I²C interface (default address 0x5A), 3.3 or 5 V power supply. Software-configurable emissivity. Applications: non-contact thermometer, thermal presence detection, industrial control.
| Sensor Type | Temperature |
|---|---|
| Measurement Range | -40°C à +125°C |
| Output Type | Analog |
| Accuracy | ±1°C |
| Digital Interface | No |
| Sensor Supply | 3.3V–5V |
| Brand | NanoSilicon |
| Mounting Type | Breadboard |
| Voltage Compatibility | 3.3V |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
