ADS1115 ADC Converter 16-bit 4-channel I2C, MSOP-10 package
€5.50
In stock
SKU
TKP-IC-CV-003
ADS1115 ADC 16-bit 4ch I2C MSOP-10, integrated PGA, high-precision instrumentation
ADS1115 analog-to-digital converter in an MSOP-10 package. 16-bit resolution, 4 channels (single-ended) or 2 channels (differential). Programmable sampling rate from 8sps to 860sps. Integrated programmable gain amplifier (PGA): ±0.256V to ±6.144V. I2C interface, 4 possible addresses. Supply voltage 2.0V–5.5V. Integrated comparator. Exceptional precision for sensors, scales and instrumentation.
| IC Family | ADC/DAC Converter |
|---|---|
| Pin Count | 16 |
| Operating Voltage | 3.3V–5V |
| IC Package | SOIC |
| Programmable | No |
| Onboard Memory | Not Applicable |
| Brand | NanoSilicon |
| Mounting Type | SMD |
| Voltage Compatibility | Multi-voltage |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
