TLC5940NT 16-Channel PWM LED Driver, DIP-28 package
Special Price
€3.90
Regular Price
€4.50
In stock
SKU
TKP-IC-DR-003
TLC5940NT 16ch PWM LED driver 12-bit DIP-28, constant current, SPI chainable
16-channel LED driver TLC5940NT in a DIP-28 package. Each channel provides a constant current source adjustable via an external resistor (up to 120mA). 12-bit PWM resolution (4096 grayscale levels) per channel. 6-bit dot correction. Daisy-chainable SPI serial interface. Supply voltage 3.0V–5.5V. Perfect for driving LED matrices, RGB strips and complex lighting displays.
| IC Family | Motor Driver |
|---|---|
| Pin Count | 16 |
| Operating Voltage | 4.5V–36V |
| IC Package | DIP |
| Programmable | No |
| Onboard Memory | Not Applicable |
| Brand | NanoSilicon |
| Mounting Type | Through-hole (THT) |
| Voltage Compatibility | 5V |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
