ADXL345 3-Axis Accelerometer Module — I²C/SPI
€4.50
In stock
SKU
TKP-SEN-MV-006
ADXL345 breakout 3-axis, ±2/4/8/16 g, I²C+SPI, tap/free-fall detection
3-axis digital accelerometer module ADXL345 on GY-291 PCB breakout. Selectable measurement ranges ±2/4/8/16 g, 13-bit resolution (4 mg/LSB in ±2 g mode). I²C (address 0x53/0x1D) and SPI (3 or 4 wire, up to 5 MHz) interfaces. 2.0 to 3.6 V power supply (onboard regulator accepts 5 V). Integrated free-fall, single/double tap, activity/inactivity detection. 32-level FIFO. Consumption 23 µA in measurement, 0.1 µA in standby. Configurable bandwidth 6.25 Hz to 3200 Hz.
| Sensor Type | Motion (PIR) |
|---|---|
| Measurement Range | 0 à 5m |
| Output Type | Analog |
| Accuracy | ±5% |
| Digital Interface | No |
| Sensor Supply | 5V |
| Brand | NanoSilicon |
| Mounting Type | Breadboard |
| Voltage Compatibility | 5V |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
