Automatic XL6019 Buck-Boost Module 1.25V–36V — 5A
€5.90
In stock
SKU
TKP-ALM-DC-003
XL6019 buck-boost, 5–32 V → 1.25–36 V auto, 5 A, 180 kHz, 90%
Automatic DC-DC buck-boost converter module based on the XL6019. Accepts input voltage from 5 to 32 V and provides adjustable output from 1.25 to 36 V. The circuit automatically switches between step-down and step-up modes depending on the input/output ratio. Max current 5 A. Frequency 180 kHz. Typical efficiency 90%. Power LED indicator. Multi-turn potentiometer for precise adjustment. 4-point screw terminal block. Dimensions 65 × 30 × 18 mm. Perfect when the source voltage fluctuates around the target voltage (e.g. car battery).
| Output Voltage | 5V |
|---|---|
| Output Current | 3A |
| Efficiency Rating | >90% |
| Regulated | Yes |
| Input Voltage | 7–35V DC |
| Output Connector | Header Pins |
| Brand | VoltCore |
| Mounting Type | SMD |
| Voltage Compatibility | Multi-voltage |
| RoHS Compliant | Yes |
| Availability | Last Units |
| Packaging | Single |
