BME280 Temperature, Humidity and Pressure Sensor Module — I²C/SPI
€7.90
In stock
SKU
TKP-SEN-TE-008
BME280 breakout, temperature/humidity/pressure, I²C+SPI, 3.3–5 V
Bosch BME280 environmental sensor module on PCB breakout with integrated voltage regulator and level-shifter. Simultaneous measurement of temperature (−40 to +85 °C, ±1 °C), relative humidity (0–100 % RH, ±3 %), and atmospheric pressure (300–1100 hPa, ±1 hPa). I²C (address 0x76/0x77) and SPI (up to 10 MHz) interfaces. 3.3 or 5 V power supply. Resolution: 0.01 °C, 0.008 % RH, 0.18 Pa. Ultra low consumption: 1.8 µA at 1 Hz. Ideal for weather station and altimeter.
| Sensor Type | Temperature |
|---|---|
| Measurement Range | -40°C à +125°C |
| Output Type | I²C |
| Accuracy | ±0.1°C |
| Digital Interface | Yes |
| Sensor Supply | 3.3V–5V |
| Brand | NanoSilicon |
| Mounting Type | Breadboard |
| Voltage Compatibility | 3.3V |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
