DHT22 Temperature and Humidity Sensor Module
Special Price
€4.50
Regular Price
€5.50
In stock
SKU
TKP-SEN-TE-002
DHT22 on breakout, temperature ±0.5 °C, humidity ±2 %, 3.3–5.5 V
DHT22 (AM2302) sensor module mounted on a PCB breakout with integrated 4.7 kΩ pull-up resistor and bypass capacitor. Measures temperature −40 °C to +80 °C (±0.5 °C) and relative humidity 0–100 % RH (±2 %). Proprietary single-wire digital interface, 3.3 to 5.5 V power supply, 1.5 mA consumption during measurement. Minimum sampling period 2 s. 3-pin connector (VCC, DATA, GND) compatible with breadboard and Dupont wires.
| Sensor Type | Temperature |
|---|---|
| Measurement Range | -40°C à +125°C |
| Output Type | I²C |
| Accuracy | ±0.5°C |
| Digital Interface | Yes |
| Sensor Supply | 3.3V–5V |
| Brand | ProtoLab |
| Mounting Type | Breadboard |
| Voltage Compatibility | 3.3V |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
