HDC1080 Humidity/Temperature Sensor Module — High-Precision I²C
Special Price
€5.50
Regular Price
€6.50
In stock
SKU
TKP-SEN-HU-007
HDC1080 breakout, humidity ±2 %, temperature ±0.2 °C, I²C, ultra-low power
Texas Instruments HDC1080 sensor module on PCB breakout. Measures relative humidity 0–100 % RH with ±2 % accuracy and temperature −40 to +125 °C with ±0.2 °C accuracy. 14-bit resolution. I²C interface (address 0x40), 2.7 to 5.5 V power supply. Ultra-low consumption: 710 nA in standby, 1.3 µA at 1 measurement/s. Configurable conversion time 6.5 ms (11-bit) to 15.5 ms (14-bit). Lowest figure of merit in its class. Ideal for IoT and battery-powered applications.
| Sensor Type | Temperature + Humidity |
|---|---|
| Measurement Range | 0 à 100% HR |
| Output Type | I²C |
| Accuracy | ±2% |
| Digital Interface | Yes |
| Sensor Supply | 3.3V–5V |
| Brand | NanoSilicon |
| Mounting Type | Breadboard |
| Voltage Compatibility | 5V |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
