3.3V/5V Bidirectional Logic Level Converter Module — 4 Channels
€2.90
In stock
SKU
TKP-PCB-SH-005
3.3V/5V bidirectional logic level converter, 4 channels, BSS138
4-channel bidirectional logic level converter module based on BSS138 transistors. Safely interfaces 3.3V circuits (ESP32, Raspberry Pi, sensors) with 5V circuits (Arduino Uno, servos). Automatic bidirectional conversion, compatible with I2C, SPI, UART and GPIO signals. Throughput up to 2 Mbps. Compact dimensions 15 × 13 mm. Pre-soldered pins. Essential for mixed 3.3V/5V projects.
| PCB Layers | Double-sided |
|---|---|
| PCB Material | FR4 |
| Board Size | Small (50×30mm) |
| Copper Thickness | 35µm (1oz) |
| Lead-free | Yes |
| Surface Finish | Lead-free HASL |
| Brand | ProtoLab |
| Mounting Type | Panel Mount |
| Voltage Compatibility | 5V |
| RoHS Compliant | Yes |
| Availability | New |
| Packaging | Single |
