Adjustable LM2596 Step-Down Module 1.25V–35V — 3A
€2.90
In stock
SKU
TKP-ALM-DC-001
LM2596 buck, 4.5–40 V → 1.25–35 V, 3 A, 150 kHz, 92% efficiency
DC-DC step-down (buck) converter module based on the LM2596 regulator. Input voltage 4.5–40 V, output voltage adjustable 1.25–35 V via multi-turn potentiometer. Max continuous current 3 A (with heatsink). Switching frequency 150 kHz. Typical efficiency 92%. Integrated Schottky freewheeling diode. Shielded 47 µH inductor. Low ESR electrolytic input and output capacitors. PCB dimensions 43 × 21 × 14 mm. Screw terminal block for input and output. Applications: embedded power supply, battery voltage reduction, Arduino projects.
| Output Voltage | 5V |
|---|---|
| Output Current | 3A |
| Efficiency Rating | >90% |
| Regulated | Yes |
| Input Voltage | 7–35V DC |
| Output Connector | Header Pins |
| Brand | VoltCore |
| Mounting Type | SMD |
| Voltage Compatibility | Multi-voltage |
| RoHS Compliant | Yes |
| Availability | Last Units |
| Packaging | Single |
