Adjustable XL6009 Step-Up Module 5V–35V — 4A boost
Special Price
€2.90
Regular Price
€3.50
In stock
SKU
TKP-ALM-DC-002
XL6009 boost, 3–32 V → 5–35 V, 4 A, 400 kHz, efficiency ≤ 94%
DC-DC step-up (boost) converter module based on the XL6009 regulator. Input voltage 3–32 V, output voltage adjustable 5–35 V via potentiometer. Max current 4 A (depending on voltage differential). Switching frequency 400 kHz. Efficiency ≤ 94%. Integrated power MOSFET with low RDS(on). Shielded toroidal inductor. Built-in thermal protection. PCB dimensions 43 × 21 × 14 mm. LM2596-compatible form factor for direct replacement. Ideal for powering high-power LEDs or boosting battery voltage.
| Output Voltage | 3.3V |
|---|---|
| Output Current | 1A |
| Efficiency Rating | >90% |
| Regulated | Yes |
| Input Voltage | 7–35V DC |
| Output Connector | Header Pins |
| Brand | VoltCore |
| Mounting Type | SMD |
| Voltage Compatibility | Multi-voltage |
| RoHS Compliant | Yes |
| Availability | Last Units |
| Packaging | Single |
