Sn63/Pb37 Solder Paste — 50g jar for SMD stencil
€16.90
In stock
SKU
TKP-OUT-FX-005
Sn63/Pb37 solder paste jar 50g, type 3, SMD stencil screen printing
Solder paste (brazing cream) Sn63/Pb37 in 50g jar. Type 3 particle size (25–45 µm) suited for stencil screen printing for SMD components down to 0.5 mm pitch. Integrated no-clean flux, ROL1 class. Viscosity optimized for regular and smear-free deposition. Recommended reflow temperature 210–230°C (peak profile). Refrigerated shelf life (2–8°C): 6 months. Bring to room temperature 2h before use. Compliant with J-STD-005.
| Tool Category | Soldering Iron |
|---|---|
| Temperature Range | Not applicable |
| Wattage | Not applicable |
| ESD-safe | No |
| Portable | Yes |
| Tip Type | Not Applicable |
| Display Type | Not Applicable |
| Brand | ProtoLab |
| Mounting Type | Not Applicable |
| Voltage Compatibility | 230V AC |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
