GL5528 LDR Photoresistor with Module — Pack of 5
€2.90
In stock
SKU
TKP-SEN-LU-001
Pack of 5 LDR GL5528 + LM393 module, analog+digital, 3.3–5 V
Pack of 5 photoresistors (LDR) GL5528, 5 mm diameter, with one LM393 comparator module included. Dark resistance ~1 MΩ, full light ~10–20 kΩ. Spectral response peak at 540 nm (green). Max power dissipation 100 mW. The module provides an analog output and a digital output with threshold adjustable by potentiometer. 3.3 to 5 V power supply. Applications: dusk switch, solar tracking, automatic nightlight, ambient brightness measurement.
| Sensor Type | Light (LDR) |
|---|---|
| Measurement Range | 0 à 100V |
| Output Type | Analog |
| Accuracy | ±5% |
| Digital Interface | No |
| Sensor Supply | 3.3V |
| Brand | NanoSilicon |
| Mounting Type | Breadboard |
| Voltage Compatibility | 3.3V |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
