Coaxial Pigtail U.FL to SMA Female — 15cm
Special Price
€2.90
Regular Price
€3.50
In stock
SKU
TKP-CAB-CX-003
Pigtail U.FL to SMA female, 15cm, RG178 50Ω, up to 6 GHz
Miniature coaxial pigtail with U.FL (IPEX/MHF) connector to SMA female (bulkhead), 15 cm long. RG178 50Ω cable, 1.8 mm diameter. Allows relocating an external SMA antenna from a WiFi, Bluetooth or LoRa module fitted with an onboard U.FL connector. Frequencies up to 6 GHz. Factory-quality soldering, controlled impedance.
| Wire Gauge | AWG 18 |
|---|---|
| Conductor Material | Bare Copper |
| Insulation Type | PVC |
| Cable Length | 1m |
| Shielded | Yes |
| Number of Conductors | 1 |
| Jacket Colour | Black |
| Brand | VoltCore |
| Mounting Type | Cable |
| Voltage Compatibility | Not Applicable |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
