LM7905CV -5V 1.5A Negative Voltage Regulator, TO-220 package
€1.10
In stock
SKU
TKP-IC-RG-005
Negative -5V 1.5A LM7905CV voltage regulator TO-220, for symmetrical ±5V supply
Negative linear voltage regulator LM7905CV in a TO-220 package. Fixed -5V output, max current 1.5A. Input voltage -7V to -35V. Thermal protection and short-circuit protection. Used in combination with an LM7805 to create a symmetrical ±5V supply, required for op-amps and bipolar analog circuits.
| IC Family | Linear Regulator |
|---|---|
| Pin Count | 3 |
| Operating Voltage | 7V–35V |
| IC Package | TO-220 |
| Programmable | No |
| Onboard Memory | Not Applicable |
| Brand | NanoSilicon |
| Mounting Type | Through-hole (THT) |
| Voltage Compatibility | Multi-voltage |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
