Wirewound cement resistor 5W 5% — 10Ω
€1.20
In stock
SKU
TKP-RES-BO-001
Wirewound cement resistor 10Ω 5W ±5%, high dissipation
Wirewound resistor in a ceramic cement housing, 10Ω, rated at 5W, ±5% tolerance. Nichrome resistance wire wound on a ceramic core, coated with refractory cement. Excellent overload and pulse withstand capability. Dimensions: 22 × 9 × 9 mm. Operating temperature up to 275°C. Used in power supplies, dimmers and braking circuits.
| Resistance Value | 10Ω |
|---|---|
| Power Rating | 5W |
| Tolerance | ±5% |
| Package Type | Through-hole |
| Temperature Coefficient | 200 ppm/°C |
| Series | E12 |
| Band Count | 4-band |
| Brand | NanoSilicon |
| Mounting Type | Through-hole (THT) |
| Voltage Compatibility | Multi-voltage |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Pack of 10 |
