Type K Thermocouple with MAX6675 Module — 0 to 700 °C
€8.90
In stock
SKU
TKP-SEN-TE-004
Thermocouple K + MAX6675, 0–700 °C, SPI, 0.25 °C resolution, stainless probe
Type K thermocouple (chromel-alumel) kit with MAX6675 conversion module on PCB breakout. Measurement range 0 °C to +700 °C, resolution 0.25 °C. SPI interface (CS, SCK, SO), 3.0 to 5.5 V power supply. Stainless steel probe with high-temperature fiberglass braided cable, 50 cm length. Cold junction compensation integrated in the MAX6675. Applications: oven, curing chamber, 3D printing, soldering control.
| Sensor Type | Temperature |
|---|---|
| Measurement Range | -40°C à +125°C |
| Output Type | One-Wire |
| Accuracy | ±0.5°C |
| Digital Interface | Yes |
| Sensor Supply | 3.3V–5V |
| Brand | NanoSilicon |
| Mounting Type | Breadboard |
| Voltage Compatibility | 3.3V |
| RoHS Compliant | Yes |
| Availability | In Stock |
| Packaging | Single |
